BROOKS SLAMf Series Elastomer Sealed Thermal Mass Flow Controllers & Meters

Features:

• Accredited with ISO/IEC 17025
• SLA Series Biotech MFC offers two options packages designed to enhance bioprocessing performance
• NEMA4X / IP66 rated hardened enclosure
• Wide range of full-scale flows from 0.003 up to 2500 lpm (36,000 lpm for meters)
• Suitable for a broad range of temperature and pressure conditions
• Industry-leading thermal flow measurement sensor technology for excellent accuracy
• Various communication options, including EtherNetIP™ and PROFINET with web-based interface for easy network configuration
• Programmable multi-gas/multi-range capabilities
• Advanced self-test routines and independent diagnostic service port for troubleshooting and changing flow conditions without removing the MFC from service

Benefits:

• Hardened device housing ensures process accuracy and control in harsh conditions
• Proprietary thermal sensing technology provides superior signal-to-noise ratio at low set points
• Long-term sensor stability reduces maintenance and recalibration requirements
• Ability to program up to six different gas calibrations on a single device
• Enhanced valve shut-off, wide turndown, certifications, and approvals (USP Class VI/ADI-free) for elastomeric materials in the gas stream (wetted path), including valve seats and o-rings
• User-accessible service port simplifies installation, troubleshooting, and diagnostics
• Excellent accuracy supported by superior metrology systems and calibration based on global standards
• EtherNet/IP™ and PROFINET allow for additional diagnostics beyond those provided by the mass flow controller alone, providing real-time system information
• ISO/IEC 17025 certification and calibration available with flow accuracy of ±0.6% of SP
• Traceable calibrations to meet industry standards and regulatory requirements

Applications:

• Life sciences
• Chemical and petrochemical pilot plants
• Blanketing in food processing
