Endress+Hauser Proline Promag H 200 electromagnetic flowmeter

Flowmeter for smallest flow rates with genuine loop-powered technology

Category:
Description

Flowmeter for smallest flow rates with genuine loop-powered technology

Specification

Measuring principle Electromagnetic
Product headline
Flowmeter for Smallest Flow Rates with Genuine Loop-Powered Technology
Designed for Measurement of Smallest Flow Quantities
Sensor features Flexible Installation with Numerous Process Connections
Energy-Saving Flow Measurement with No Pressure Loss
Maintenance-Free Design with No Moving Parts
Liner Material: PFA
Sensor Housing: Stainless Steel
Various Electrode Materials Available
Transmitter features Convenient Device Wiring with Separate Connection Compartment
Safe Operation with Display, Touch Control, and Background Lighting
Integrated Verification with Heartbeat Technology
Loop-Powered Technology
Robust Dual-Compartment Housing
Worldwide Approvals (SIL, Hazardous Area)
Nominal diameter range DN 2 to 25 (¹⁄₁₂ to 1″)
Wetted materials Liner: PFA
Electrodes: 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022); Tantalum; Platinum
Process Connections: stainless steel, 1.4404 (F316L); PVDF; PVC adhesive sleeve
Seals: O-ring seal (EPDM, FKM, Kalrez), aseptic molded seal (EPDM, FKM, silicone)
Grounding Rings: stainless steel, 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022); tantalum
Measured variables Volume flow, mass flow
Max. measurement error Volume flow: ±0.5 % o.r. ± 2 mm/s (0.08 in/s)
Measuring range 0.06 dm³/min to 300 m³/h (0.015 to 80 gal/min)
Max. process pressure PN 40, Class 150, 20K
Medium temperature range –20 to +150 °C (–4 to +302 °F)
Ambient temperature range –40 to +60 °C (–40 to +140 °F)
Sensor housing material 1.4301 (304), corrosion resistant
Transmitter housing material AlSi10Mg, coated
Degree of protection IP66/67, type 4X enclosure
Display/Operation 4‐line backlit display with touch control (operation from outside)
Configuration via local display and operating tools possible
Remote display available
Outputs 4‐20 mA HART (passive)
Pulse/frequency/switch output (passive)
Inputs None
Digital communication HART, PROFIBUS PA, FOUNDATION Fieldbus
Power supply DC 18 to 35 V (4‐20 mA HART with/without pulse/frequency/switch output)
Hazardous area approvals ATEX, IECEx, cCSAus, NEPSI, INMETRO, EAC, JPN, UK Ex
Product safety CE, C-tick
Functional safety Functional safety according to IEC 61508, applicable in safety-relevant applications in accordance with IEC 61511
Metrological approvals and certificates Calibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)
Heartbeat Technology complies with the requirements for measurement traceability according to ISO 9001:2015 – Section 7.1.5.2 a (TÜV SÜD attestation)
Pressure approvals and certificates CRN
Material certificates 3.1 material
