Honeywell Smartline ST800-STG800 Gauge Pressure Transmitter
The SmartLine® ST800 Gauge Pressure Transmitters provide excellent performance and are well-suited for high-pressure measurements in boilers, fuel feeds, and tank level applications with relatively high process temperatures.
Description
The SmartLine® ST800 Gauge Pressure Transmitters provide excellent performance and are well-suited for high-pressure measurements in boilers, fuel feeds, and tank level applications with relatively high process temperatures.
ST800 Dual Head Gauge Pressure Transmitters are suited for applications requiring small flange or 1/2” NPT connections. Typical applications include gauge pressure measurement of reaction vessels in the chemical industry and level applications with process temperatures of up to 302°F /150°C.
In-Line transmitters are screwed directly onto a 1/2” male NPT nipple and can be installed in hazardous environments for accurate, repeatable pressure measurement. Typical applications include high-pressure measurement in boilers, fuel feeds and high-pressure reaction vessels in the petrochemical and hydrocarbon recovery industries.
The following models are available:
| Model | Range(psi) | Range(Bar) |
| STG830/STG83L | 0-50 | 0-3.5 |
| STG840/STG84L | 0-500 | 0-35 |
| STG870/STG87L | 0-3,000 | 0-210 |
| STG88L | 0-6,000 | 0-420 |
| STG89L | 0-10,000 | 0-690 |
