Rosemount 3051HT Hygienic Pressure Transmitter
Experience the exceptional performance of the Rosemount 3051HT Hygienic Pressure Transmitter, a cutting-edge solution for precise gage and absolute measurements in the pharmaceutical, food, and beverage sectors. Engineered with standard process connections, this transmitter seamlessly integrates with sanitary fittings, eliminating the need for specialized mounting hardware. It fully adheres to renowned industry standards such as 3-A™, EHEDG, and ASME-BPE, and provides the option of a polished stainless steel housing for a sleek appearance. Embrace this outstanding transmitter to achieve unmatched performance in hygienic environments without any compromise.
Experience the exceptional performance of the Rosemount 3051HT Hygienic Pressure Transmitter, a cutting-edge solution for precise gage and absolute measurements in the pharmaceutical, food, and beverage sectors. Engineered with standard process connections, this transmitter seamlessly integrates with sanitary fittings, eliminating the need for specialized mounting hardware. It fully adheres to renowned industry standards such as 3-A™, EHEDG, and ASME-BPE, and provides the option of a polished stainless steel housing for a sleek appearance. Embrace this outstanding transmitter to achieve unmatched performance in hygienic environments without any compromise.
Specifications
| Warranty |
Up to 5-year limited warranty
|
| Rangedown |
Up to 100:1
|
| Communication Protocol | 4-20 MA HART®, FOUNDATION™ fieldbus, PROFIBUS® PA |
| Measurement Range | Up to 800 psig (55,7 bar) gage Up to 150 psia (10,3 bar) absolute |
| Process Wetted Material | 316L SST mechanically polished and electropolished to Ra < 15 μ-in. (0.38 μ-m) |
| Diagnostics | Basic Diagnostics, Process Alerts, Loop Integrity Diagnostics, Plugged Impulse Line Diagnostics |
| Certifications/Approvals | 3A, EHEDG, ASME-BPE, see full specs for complete list of certifications |
| Update Rate | 1 sec. to 60 min., user selectable |
| Power Module Life | Up to 10-year life, field replaceable (order separately) |
| Wireless Range | Internal antenna (225 m) |
| Features |
Offers best-in-class performance of 0.065% of span, 100:1 rangedown, and 5-year stability, with batch repeatability up to ±0.02% upper range limit for 60 batches
Polished stainless steel housing is free of voids and crevices to ensure easy cleaning and withstand washdown conditions (IP66/68 rated) for long term performance and durability
Connects to various industry standard sanitary fittings including Tri-Clamp, Varivent, and DIN 11851 connection styles, see full specs for complete list of options
Application specific configuration allows you to transform your pressure transmitter into a level transmitter with volume calculations
Bluetooth® wireless connectivity unlocks a far simpler process to perform maintenance and service tasks without the need for a physical connection or separate configuration tool
The graphical, back-lit display allows for easy operation in 8 different languages in all lighting conditions
Loop Integrity and Plugged Impulse Line diagnostics detect electrical loop issues and plugged impulse piping before it impacts the quality of the process for increased safety and reduced downtime
Local Operator Interface (LOI) for simple, local commissioning on-site without the use of extra tools
Meets 3-A, EHEDG and ASME-BPE standards to meet industry-specific requirements
|
