SIEMENS SITRANS FM MAG 5000 electromagnetic flow transmitter
The transmitter is truly robust, cost-effective and suitable for all-round applications and has a measuring accuracy of ± 0.4% of the flow rate (incl. sensor).
Description
| Accuracy | 0.4 % ±1 mm/s, 1 current output |
| Input / output | 1 digital output, 1 relay output |
| Communication | HART |
| Display | Background illumination with alphanumeric text, 3 x 20 characters |
| Enclosure | IP67 (NEMA 4x/6)
IP20 (NEMA 2) |
| Power supply | 12-24 V a.c./d.c.
115-230 V a.c. |
| Ambient temperature | From -20 to 50 °C (-4 to 122 °F) |
| Approvals | MI-001
Danak PTB OIML R49 |
| Ex-approvals | FM/CSA Class 1, Div 2 |
Benefits:
- Cost-effective transmitter offering high performance.
- Rugged construction suitable for universal applications and providing high measurement accuracy.
- Multiple function outputs for efficient process control.
- Display and keypad available in several languages, ensuring ease of use.
- Integration with SITRANS FM portfolio: The MAG 500/6000 transmitter can be flexibly used with all products (MAG 5100/3100/1100).
- Unique SensorProm technology: Critical, sensor-specific data is stored and passed to the transmitter, allowing for simple and flexible sensor commissioning.
- Plug & Play: Enables easy on-site replacement and commissioning of the transmitter in just minutes.
- “Hot swappable”: The transmitter can be exchanged during operation.
- Mounting flexibility: Compact or separate installation options are available.
- Validated calibration: Each Siemens flowmeter is calibrated in facilities accredited to ISO/IEC 17025, ensuring accurate flow measurement.
- Service and diagnostics: Designed for MAG on-site verification with traceable certification. Regular calibration of the SITRANS FM Verificator ensures accuracy in the field.
